Indoor Lights

Spotlight

Product Image

Revo

Product Image

Revo

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
REV 975 9W 720 lm Φ75 Φ75 IP20/IP44 15°
24°
38°
REV 1275 12W 960 lm Φ75 Φ75
REV 15100 15W 1200 lm Φ100 Φ100
REV 20100 20W 1600 lm Φ100 Φ100
REV 25125 25W 2000 lm Φ125 Φ125
REV 30125 30W 2400 lm Φ125 Φ125
REV 35150 35W 2800 lm Φ150 Φ150
REV 40150 40W 3200 lm Φ150 Φ150
Product Image

Revo Adjustable

Product Image

Revo Adjustable

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
REV A 975 9W 720 lm Φ90x83 Φ75 IP20/IP44 15°
24°
38°
REV A 1275 12W 960 lm Φ90x83 Φ75
REV A 15100 15W 1200 lm Φ115x115 Φ100
REV A 20100 20W 1600 lm Φ115x115 Φ100
REV A 25125 25W 2000 lm Φ140x145 Φ125
REV A 30125 30W 2400 lm Φ140x145 Φ125
REV A 35150 35W 2800 lm Φ165x160 Φ150
REV A 40150 40W 3200 lm Φ165x160 Φ150
Product Image

Revo SQ

Product Image

Revo SQ

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
REV S 975 9W 630 lm 90x90x97 75x75 IP20/IP44 15°
24°
38°
REV S 1275 12W 840 lm 90x90x97 75x75
REV S 15100 15W 1050 lm 115x115x127 100x100
REV S 20100 20W 1400 lm 115x115x127 100x100
REV S 25125 25W 1750 lm 140x140x160 125x125
REV S 30125 30W 2100 lm 140x140x160 125x125
REV S 35150 35W 2450 lm 165x165x175 150x150
REV S 40150 40W 2800 lm 165x165x175 150x150
Product Image

Revo Trimless Adjustable

Product Image

Revo Trimless Adjustable

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
REV TA 975 9W 630 lm Φ115x100 Φ80 IP20/IP44 15°
24°
38°
REV TA 1275 12W 840 lm Φ115x100 Φ80
REV TA 15100 15W 1050 lm Φ140x130 Φ105
REV TA 20100 20W 1400 lm Φ140x130 Φ105
REV TA 25125 25W 1750 lm Φ165x151 Φ130
REV TA 30125 30W 2100 lm Φ165x151 Φ130
REV TA 35150 35W 2450 lm Φ190x179 Φ155
REV TA 40150 40W 2800 lm Φ190x179 Φ155
Product Image

Vanus

Product Image

Vanus

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
VAN A 565 5W 375 lm Ф65*48 Ф55 IP20 24°
VAN A 785 7W 560 lm Ф85*51 Ф75
VAN A 985 9W 720 lm Ф85*51 Ф75
VAN A 1285 12W 960 lm Ф85*51 Ф75
VAN A 12105 12W 960 lm Ф105*51 Ф95
VAN A 15105 15W 1200 lm Ф105*61 Ф95
Product Image

Losa

Product Image

Losa

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
LOS A 683 6W 510 lm Φ83 x H68 Ф73 IP20 15°
24°
38°
60°
LOS A 883 8W 680 lm Φ83 x H68 Ф73
LOS A 990 9W 720 lm Φ90 x H83 Ф78
LOS A 1292 12W 1020 lm Φ90 x H83 Ф78
LOS A 15110 15W 1275 lm Φ110 x H93 Ф95
LOS A 20120 20W 1700 lm Φ120 x H93 Ф105
LOS A 30150 30W 2550 lm Φ150 x H103 Ф135
LOS A 40150 40W 3400 lm Φ150 x H103 Ф135
Product Image

Rota

Product Image

Rota

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
ROT 1090 10W 1050 lm Ø90×60mm Ø75mm IP20 15°
24°
38°
60°
ROT 15102 15W 1570 lm Ø102×80mm Ø90mm
ROT 24125 24W 2520 lm Ø125×110mm Ø110mm
ROT 30140 30W 3100 lm Ø140×115mm Ø128mm
ROT 40160 40W 4200 lm Ø160×135mm Ø148mm
ROT 50190 50W 5200 lm Ø190×175mm Ø180mm
Product Image

Spotty

Product Image

Spotty

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
SPO 345 3W 150 lm Φ45*44 Φ40 IP20 15°
24°
38°
SPO 558 5W 250 lm Φ58*66 Φ50
SPO 868 8W 560 lm Φ68*77 Φ60

Downlight

Product Image

Pico

Product Image

Pico

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
PIC 9100 9W 765 lm Φ100x75 Φ90 IP20/IP44 60°
PIC 12100 12W 1020 lm Φ100x75 Φ90
PIC 15110 15W 1275 lm Φ110x80 Φ100
PIC 20110 20W 1700 lm Φ110x80 Φ100
PIC 20135 20W 1700 lm Φ135x96 Φ125
PIC 30135 30W 2550 lm Φ135x96 Φ125
PIC 30170 30W 2550 lm Φ170x112 Φ158
PIC 40170 40W 3400 lm Φ170x112 Φ158
PIC 40215 40W 3400 lm Φ215x135 Φ200
PIC 50215 50W 4250 lm Φ215x135 Φ200
Product Image

Meo

Product Image

Meo

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MEO 15135 15W 1200 lm Φ135*66 Φ120 IP20 90°
MEO 30190 30W 2400 lm Φ190*90 Φ170
MEO 40224 40W 2550 lm Φ224*98 Φ200
Product Image

Gen

Product Image

Gen

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
GEN 10115 10W 800 lm Φ115*50 Φ100 IP44 60°
GEN 20160 20W 1600 lm Φ160*60 Φ145
GEN 30190 30W 2400 lm Φ190*60 Φ175
GEN 35230 35W 2800 lm Φ230*72 Φ210
Product Image

Ceno

Product Image

Ceno

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
CEN 10100 10W 850 lm Φ100*75 Φ90 IP20/IP44/IP65 30°
45°
CEN 10140 20W 1700 lm Φ140*90 Φ130
CEN 30185 30W 2550 lm Φ185*112 Φ170
CEN 40230 40W 3400 lm Φ230*128 Φ200
Product Image

Leno

Product Image

Leno

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
LEN 884 8W 824lm Φ84 Φ75 IP44 15°
24°
36°
60°
LEN 15105 15W 1700lm Φ105 Φ95
LEN 20136 20W 2200lm Φ136 Φ120
LEN 30162 30W 3200lm Φ162 Φ150
LEN 40213 40W 4200lm Φ213 Φ200
Product Image

Roket

Product Image

Roket

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
ROK 35150 35W 2800 lm Φ150*H102 Φ135 IP20 15°
24°
38°
60°
ROK 50160 50W 4250 lm Φ160*H103 Φ145
ROK 60180 60W 4800 lm Φ180*H110 Φ165
ROK 80180 80W 6400 lm Φ180*H125 Φ165
ROK 60235 60W 4800 lm Φ235*H120 Φ205
ROK 80235 80W 6400 lm Φ235*H130 Φ205
Product Image

Cloud

Product Image

Cloud

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
CLO 885 8W 640 lm Ф85*36 Φ135 IP20/IP44 110°
CLO 12100 12W 960 lm Ф100*36 Φ145
CLO 15110 15W 1275 lm Ф110*36 Φ165
CLO 20140 20W 1600 lm Ф140*38 Φ165
CLO 24155 24W 1920 lm Ф155*38 Φ205
CLO 30165 30W 2400 lm Ф165*38 Φ205
CLO 40215 40W 3200 lm Ф215*41 Φ205
Product Image

Opal

Product Image

Opal

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
OPA 15109 15W 1650 lm Φ109*H50mm Φ90mm IP20; IP54 100°
OPA 20134 20W 2200 lm Φ134*H50mm Φ115mm
OPA 25160 25W 2750 lm Φ160**H52mm Φ140mm
OPA 35188 35W 3850 lm Φ188*H52mm Φ170mm
OPA 42227 42W 4620 lm Ø227*H52mm Φ200mm
Product Image

Opal PRO

Product Image

Opal PRO

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
OPA P 15104 15W 1650 lm Ø104*H69mm Ø90-95mm IP20; IP54 85°
OPA P 129 20W 2200 lm Ø129*H69mm Ø115-120mm
OPA P 25155 25W 2750 lm Ø155*H74mm Ø140-145mm
OPA P 35190 35W 3850 lm Ø190*H74mm Ø170-178mm
OPA P 220 42W 4620 lm Ø220*H84mm Ø200-208mm
Product Image

Opal Flat

Product Image

Opal Flat

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
OPA F 15135 15W 1500 lm Ø135×H38mm Ø125mm IP50 150°
OPA F 170 22W 2200 lm Ø170×H38mm Ø150mm
OPA F 228 32W 3200 lm Ø228×H38mm Ø200mm

IP Downlight

Product Image

Cacy

Product Image

Cacy

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
CAC 10100 10W 1000 lm Ø100mm×H48mm Ø80mm IP65
Safety Glass		 15°
24°
38°
45°
60°
CAC 15100 15W 1500 lm Ø100mm×H68mm Ø80mm
CAC 25100 25W 2500 lm Ø100mm×H96mm Ø80mm
Product Image

Milo

Product Image

Milo

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MIL 865 8W 800 lm Ø65mm×H76mm Ø55mm IP65
Safety Glass		 Reflector 20°| 40°|60° Lens 15°| 24°|36°|50°
MIL 1085 10W 1000 lm Ø85mm×H74mm Ø75mm Reflector 15°| 24°|38°|45°|60° Lens 15°| 24°|36°
MIL 1585 15W 1500 lm Ø85mm×H94mm Ø75mm Reflector 15°| 24°|38°|45°|60°
MIL 2585 25W 2500 lm Ø85mm×H122mm Ø75mm Reflector 15°| 24°|38°|45°|60°
MIL 28105 28W 2800 lm Ø105mm×H125mm Ø95mm Reflector 15°| 24°|38°|45°|60°
Product Image

Milo SQ

Product Image

Milo SQ

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MIL 865 8W 800 lm L65×W65×H60mm L55xW55mm IP65
Safety Glass		 Reflector 20°| 40°|60° Lens 15°| 24°|36°|50°
MIL 1085 10W 1000 lm L85×W85×H76mm L75xW75mm Reflector 15°| 24°|38°|45°|60° Lens 15°| 24°|36°
MIL 1585 15W 1500 lm L85×W85×H76mm L75xW75mm Reflector 15°| 24°|38°|45°|60°
MIL 2585 25W 2500 lm L85×W85×H122mm L75xW75mm Reflector 15°| 24°|38°|45°|60°
MIL 28105 28W 2800 lm L105×W105×H108mm L95xW95mm Reflector 15°| 24°|38°|45°|60°
Product Image

Eilo

Product Image

Eilo

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
EIL 893 8W 800 lm Ø93mm×H85mm Ø80mm IP65
Safety Glass		 Reflector 20°| 40°|60° Lens 15°| 24°|36°|50°
EIL 1593 15W 1500 lm Ø93mm×H86mm Ø80mm Reflector 20°| 40°|60° Lens 15°| 24°|36°|50°
EIL 10110 10W 1000 lm Ø110mm×H78mm Ø95mm Reflector 15°| 24°|38°|45°|60°
EIL 15110 15W 1500 lm Ø110mm×H98mm Ø95mm Reflector 15°| 24°|38°|45°|60° Lens15°| 24°|38°
EIL 25110 25W 2500 lm Ø110mm×H124mm Ø95mm Reflector 15°| 24°|38°|45°|60°
EIL 28135 28W 2800 lm Ø135mm×H125mm Ø120mm Reflector 15°| 24°|38°|45°|60°
Product Image

Eilo SQ

Product Image

Eilo SQ

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
EIL S 888 8W 800 lm L88xW88×H85mm L80×W80m IP65
Safety Glass		 Reflector 20°| 40°|60° Lens 15°| 24°|36°|50°
EIL S 1588 15W 1500 lm L88xW88×H86mm L80×W80mm Reflector 20°| 40°|60° Lens 15°| 24°|36°|50°
EIL S 10106 10W 1000 lm L106xW106×H78mm L95×W95mm Reflector 15°| 24°|38°|45°|60°
EIL S 15106 15W 1500 lm L106xW106×H98mm L95×W95mm Reflector 15°| 24°|38°|45°|60° Lens15°| 24°|38°
EIL S 25106 25W 2500 lm L106xW106×H124mm L95×W95mm Reflector 15°| 24°|38°|45°|60°
EIL S 28129 28W 2800 lm L129xW129×H125mm L120×W120mm Reflector 15°| 24°|38°|45°|60°
Product Image

ORIS

Product Image

ORIS

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
ORI 18134 8W 800 lm L88xW88×H85mm L80×W80m IP65
Safety Glass		 60°
ORI 28160 15W 1500 lm L88xW88×H86mm L80×W80mm
ORI 38188 10W 1000 lm L106xW106×H78mm L95×W95mm
ORI 48250 15W 1500 lm L106xW106×H98mm L95×W95mm

Grid Downlight

Product Image

OLFA

Product Image

OLFA

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
OLF S 554 5W 425 lm 54*54*50 49*49 IP20 15°/24°/38°/ 55°
OLF S 12130 12W 1020 lm 130*54*52 125*49
OLF S 1592 15W 1275 lm 92*92*52 87*87
OLF S 20206 20W 1700 lm 206*54*52 201*49
OLF S 36130 36W 3060 lm 130*130*52 125*125
OLF S 40396 40W 3400 lm 396*54*52 390*49
Product Image

Cetrus

Product Image

Cetrus

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
CET1 9103 1*9W 765 lm 103*103*88 93*93 IP20 15°
24°
38°
60°
CET1 15132 1*15W 1275 lm 132*132*110 122*122
CET1 30156 1*30W 2550 lm 156*156*135 146*146
CET2 9181 2*9W 2*765 lm 181*103*88 171*93
Product Image

Cetrus Pro

Product Image

Cetrus Pro

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
CET1 9103 9W 765 lm 116x116x90 100x100 IP20 15°
24°
38°
60°
CET1 15132 15W 1275 lm 144x144x110 125x125
CET1 30156 25W 2125 lm 164x164x113 145x145
CET2 9181 35W 2975 lm 184x184x115 165x165
CET2 9181 2*9W 1530 lm 116x222x90 100x200

Surface & Suspended

Product Image

Cillo

Product Image

Cillo

Code Power (W) Lumen Ouput (lm) Dimension (mm) IP Rate Beam Angle
CIL 855 8W 680 lm Φ55*165 IP20 15°
24°
38°
CIL 1255 12W 1020 lm Φ55*205
CIL 1555 15W 1275 lm Φ55*245
CIL 1565 15W 1275 lm Φ65*165
CIL 2065 20W 1700 lm Φ65*205
CIL 2565 25W 2125 lm Φ65*245
CIL 2075 20W 1700 lm Φ75*165
CIL 2575 25W 2125 lm Φ75*205
CIL 3075 30W 2550 lm Φ75*245
Product Image

OLI Pro

Product Image

OLI Pro

Code Power (W) Lumen Ouput (lm) Dimension (mm) IP Rate Beam Angle
OL P1075 10W 1050 lm Ø75×H.100mm IP20 20°
40°
OL P1575 15W 1570 lm Ø75×H.152mm
OL P1595 15W 1570 lm Ø95×H.100mm
OL P2095 20W 2100 lm Ø95×H.152mm
OL P30115 30W 3150 lm Ø115×H.152mm
OL P40140 40W 4200 lm Ø140×H.162mm
OL P50170 50W 5250 lm Ø170×H.182mm
OL P50205 50W 5250 lm Ø205×H.212mm
Product Image

Novia

Product Image

Novia

Code Power (W) Lumen Ouput (lm) Dimension (mm) IP Rate Beam Angle
NOV 1590 50W 1500 lm Ø90×H99mm IP65 60°
NOV 30120 30W 3000 lm Ø120×H118mm
NOV 50168 50W 5000 lm Ø168×H120mm
Product Image

Novia Opal

Product Image

Novia Opal

Code Power (W) Lumen Ouput (lm) Dimension (mm) IP Rate Beam Angle
NOV OP1590 50W 1500 lm Ø90×H99mm IP65 110°
NOV OP30120 30W 3000 lm Ø120×H118mm
NOV OP50168 50W 5000 lm Ø168×H120mm
Product Image

OLI

Product Image

OLI

Code Power (W) Lumen Ouput (lm) Dimension (mm) IP Rate Beam Angle
OL 755 7W 560 lm Φ55*110 IP65 15°/24°/38°/45°/60°
OL 955 9W 720 lm Φ55*120
OL 1275 12W 960 lm Φ75*116
OL 1575 15W 1200 lm Φ75*116
OL 1595 15W 1200 lm Φ95*150
OL 2095 20W 1600 lm Φ95*150
OL 25113 25W 2000 lm Φ113*150
OL 30140 30W 2400 lm Φ140*160
OL 40170 40W 3200 lm Φ170*195

Frames & Panels

Product Image

Pano P

Product Image

Pano P

Code Power (W) Lumen Ouput (lm) Dimension (mm) IP Rate Beam Angle
PAN P 24300 24W 1920 lm Φ300*20*1200 IP20 120°
PAN P 30400 30W 2550 lm Φ400*20*1200
PAN P 40500 40W 3400 lm Φ500*20*1200
PAN P 48600 48W 4080 lm Φ600*20*1200
PAN P 72800 72W 5950 lm Φ800*20*1200
PAN P 961000 96W 7680 lm Φ1000*20*1200
Product Image

Pano SS

Product Image

Pano SS

Code Power (W) Lumen Ouput (lm) Dimension (mm) IP Rate Beam Angle
PAN SS 24300 24W 1920 lm Φ300*20*1200 IP20 120°
PAN SS 30400 30W 2550 lm Φ400*20*1200
PAN SS 40500 40W 3400 lm Φ500*20*1200
PAN SS 48600 48W 4080 lm Φ600*20*1200
PAN SS 72800 72W 5950 lm Φ800*20*1200
PAN SS 961000 96W 7680 lm Φ1000*20*1200
Product Image

Pano ST

Product Image

Pano ST

Code Power (W) Lumen Ouput (lm) Dimension (mm) IP Rate Beam Angle
PAN ST 24400 24W 1800 lm Ф400*70 IP20 120°
PAN ST 40500 40W 3000 lm Ф500*70
PAN ST 50600 50W 3750 lm Ф600*70
PAN ST 80800 80W 6000 lm Ф800*70
PAN ST 961000 96W 7200 lm Ф1000*70

Track Light

Product Image

Blaze

Product Image

Blaze

Code Power (W) Lumen Ouput (lm) Dimension (mm) Adaptor IP Rate Beam Angle
BLA 2095 20W 1700 lm 221*95*210(D95/110) 4 wires IP20 15°
24°
38°
BLA 3095 30W 2550 lm 221*95*230(D95/130) 4 wires
BLA 4095 40W 3400 lm 221*95*250(D95/150) 4 wires
BLA 50107 50W 4250 lm 221*107*240(D107/140) 4 wires
Product Image

Trako

Product Image

Trako

Code Power (W) Lumen Ouput (lm) Dimension (mm) Adaptor IP Rate Beam Angle
TRA 18220 18W 1800 lm 70x60x220（60/161） 4 wires IP20 15°
24°
36°
55°
TRA 25229 25W 2500 lm 70x70x229（70/170） 4 wires
TRA 32239 32W 3200 lm 70x80x239（80/180） 4 wires
Product Image

Waly

Product Image

Waly

Code Power (W) Lumen Ouput (lm) Dimension (mm) Adaptor IP Rate Beam Angle
WAL 857286 8W 680 lm 86*57*286 (57*165) 4 wires IP20 15°
24°
38°
WAL 1557286 15W 1275 lm 86*57*286 (57*165) 4 wires
WAL 1571326 15W 1275 lm 86*71*326 (71*190) 4 wires
WAL 2071326 20W 1700 lm 86*71*326 (71*190) 4 wires

Magnetic Light

Product Image

Magno Linear Opal

Product Image

Magno Linear Opal

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MTLO6112 6W 480 lm 112mm*23mm*45mm NA IP20 120°
MTLO8220 8W 640 lm 220mm*23mm*45mm
MTLO12328 12W 960 lm 328mm*23mm*45mm
MTLO15436 15W 1200 lm 436mm*23mm*45mm
MTLO20652 20W 1600 lm 652mm*23mm*45mm
MTLO22868 22W 1760 lm 868mm*23mm*45mm
Product Image

Magno Linear Opal ADJ

Product Image

Magno Linear Opal ADJ

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MTLO6112A 6W 480 lm 112mm*23mm*30+53mm NA IP20 120°
MTLO12328A 12W 960 lm 220mm*23mm*30+53mm
MTLO18328A 18W 1440 lm 328mm*23mm*30+53mm
Product Image

Magno Linear DOT

Product Image

Magno Linear DOT

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MTLD6112 6W 540 lm 112mm*23mm*45mm NA IP20 24°
36°
MTLD8220 8W 720 lm 220mm*23mm*45mm
MTLD12328 12W 1080 lm 328mm*23mm*45mm
MTLD15436 15W 1350 lm 436mm*23mm*45mm
MTLD20652 20W 1800 lm 652mm*23mm*45mm
MTLD22868 22W 1980 lm 868mm*23mm*45mm
Product Image

Magno Linear DOT ADJ

Product Image

Magno Linear DOT ADJ

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MTLD6112A 6W 540 lm 112mm*23mm*30+53mm NA IP20 24°
36°
MTLD12220A 12W 1080 lm 220mm*23mm*30+53mm
MTLD18328A 18W 1620 lm 328mm*23mm*30+53mm
Product Image

Magno Linear Cylinder

Product Image

Magno Linear Cylinder

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MTLC5123 5W 450 lm 123mm*32mm*76mm NA IP20 24°
36°
MTLC10231 10W 900 lm 231mm*32mm*76mm
MTLC15339 15W 1350 lm 339mm*32mm*76mm
Product Image

Magno Linear Cylinder Opal ADJ

Product Image

Magno Linear Cylinder Opal ADJ

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MTLCO5123A 5W 450 lm 123mm*32mm*76mm NA IP20 24°
36°
MTLCO10231A 10W 900 lm 231mm*32mm*76mm
MTLCO15339A 15W 1350 lm 339mm*32mm*76mm
Product Image

Magno Spot

Product Image

Magno Spot

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MTS32550 3W 270 lm Φ25*50mm NA IP20 24°
15°
24°
38°
MTS53585 5W 450 lm Φ35*85mm
MTS745110 7W 630 lm Φ45*110mm
MTS1055125 10W 900 lm Φ55*125mm
MTS1565130 15W 1350 lm Φ65*130mm
MTS2075135 20W 1800 lm Φ75*135mm
Product Image

Magno Tube

Product Image

Magno Tube

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MTT54590 5W 450 lm Φ45*90mm NA IP20 20°
40°
60°
MTT1045120 10W 900 lm Φ45*120mm
MTT1545200 15W 1350 lm Φ45*200mm
Product Image

Magno Deco A B C D

Product Image

Magno Deco A B C D

Code Power (W) Lumen Ouput (lm) Dimension (mm) Cut Out (mm) IP Rate Beam Angle
MTD12100A 12W 450 lm Φ100*L1000mm NA IP20 20°
40°
60°
MTD12100B 12W 900 lm Φ100mm
MTDC7100C 7W 1350 lm Φ100*L1000mm
MTDC7100D 7W 1350 lm Φ100mm
Product Image

Track Rail

Get Consultation

Get A Free Consultation Contact Us !

Get Consultations
